Mini ESS for Solar Dealers and Installers

Select Mini ESS models for your customers.

We help solar dealers and installers match household loads with Mini ESS capacity, charging inputs and installation requirements.

SOLAR CHANNEL

Mini ESS for Solar Dealers and Installers

We help solar dealers and installers match household loads with Mini ESS capacity, charging inputs and installation requirements.

01

Start with the household load

List lighting, fans, communication devices and other essential loads before choosing a model. Separate simultaneous output from stored energy so the recommendation remains tied to the customer’s actual use.

02

Check the charging and placement brief

Match panel voltage and power to the selected model, confirm AC charging requirements and choose a suitable installation location. W series models support wall mounting.

03

Explain operation and service to your customer

Explain the supported loads, expected runtime under those loads, charging requirements and after-sales arrangements. Send us the appliance list if you need help selecting a model.

04

PV voltage windows and maximum solar input

B series models accept 200W–400W PV at 12–60V; A300–A1000 models accept 250W–550W at 12–60V; W1000R accepts 600W at 12–60V DC and W1000S accepts 550W at 11–55V. Higher-capacity A1500S/A2000S (18–110V) and W1500S/W2000S (18–120V) support up to 1200W PV input.

05

Solar-only B series vs hybrid AC + PV series

The B series is supplied without an AC-DC adapter for solar-primary packages, whereas A, W and US series models support both AC wall charging and solar panel input with pure sine wave AC output.

06

Wall-mounted and portable formats

Specify W1000R (420 × 400 × 92 mm) or W1000S/W1500S/W2000S for wall-mounted residential installations, or choose portable A and B series units with LiFePO4 battery chemistry for flexible room-to-room use.
