W SERIESLiFePO4
MODEL: lite EU W1000R · Series: W Series Wall-Mounted Mini ESS
lite EU W1000R
The lite EU W1000R is an integrated Mini ESS for portable or wall-mounted use. Capacity is 2000Wh; rated AC output is 1000W pure sine wave at 220V and 50HZ/60HZ. Charging inputs are PV 12-60Vdc, maximum 600W; AC 180-253V, maximum 1000W. Interfaces: USB-A: 5V/2A, 2 ports, 10W max per port; USB-C: 5V/2A, 10W max per port. Use it with appliances and digital devices whose combined demand stays within 1000W.
CAPACITY2000Wh
RATED OUTPUT1000W
PV MAX INPUT600W
CELL CHEMISTRYLiFePO4
SOURCING TERMS
Direct manufacturer20-ft containerMOQ PER MODEL
250,000 unitsANNUAL CAPACITY
20,000 unitsMONTHLY OUTPUT
Sampling and production lead times are confirmed per enquiry.
Confirm model MOQCompare modelsProduct documentationlite EU W1000R Product ManualEnglish PDF · Opens in a new tabView or download
✓ LiFePO4 cells✓ Pure sine wave output✓ Solar + AC charging
Technical specifications
W1000R specifications
| Parameter | Specification |
|---|---|
| AC output | |
| Rated output | 1000W |
| Waveform | Pure sine wave |
| AC voltage | 220V |
| AC frequency | 50HZ/60HZ |
| Rated output current | 4.35A |
| AC socket count | Universal Socket*2 |
| USB-A | 5V/2A, 2 ports, 10W max per port |
| USB-C | 5V/2A, 10W max per port |
| Battery | |
| Rated capacity | 2000Wh |
| Chemistry | LiFePO4 |
| Nominal voltage | 3.2V*2 |
| Cycle life | 6000 cycles @ 95% DoD |
| BMS protection | Short-circuit, overcurrent, overvoltage, over-temperature, PV input reverse connection, battery overcharge and overdischarge, high and low temperature protection for battery cells, etc |
| Charging & input | |
| PV input voltage | 12-60Vdc |
| PV max input | 600W |
| PV start voltage | 16Vdc |
| Max input current | 16A |
| AC input range | 180-253V |
| AC input terminal | C1 4 Plug×1 |
| AC max charge | 1000W |
| Physical | |
| Enclosure | Metal spraying |
| Form factor | Portable or wall-mounted |
| Dimensions | 420×400×92mm（Hand-measuring, small gap is possible） |
| Net weight | ≈18kg |
| IP rating | IP20 |
| Cooling | Forced-air |
| Environment | |
| Charge temperature | -0°C-45°C |
| Humidity | 10%-90% |
| Operating altitude | ≤3000m |
| Commercial | |
| MOQ | one 20-foot container per model |
| Warranty | 24 months; see order terms |
| OEM / ODM | |
| Housing color | DARK BLACK/WHITE |
