US SERIESLiFePO4
MODEL: lite US A500C · Series: US Mini ESS
lite US A500C
Designed for household use and portable outdoor power, the lite US A500C combines 800Wh LiFePO4 storage with 500W pure sine wave output at 100–120V, 60Hz. Charge from an 85–135V AC supply or 12–60V solar panels with up to 300W PV input.
CAPACITY800Wh
RATED OUTPUT500W
PV MAX INPUT300W
CELL CHEMISTRYLiFePO4
SOURCING TERMS
Direct manufacturer20-ft containerMOQ PER MODEL
250,000 unitsANNUAL CAPACITY
20,000 unitsMONTHLY OUTPUT
Sampling and production lead times are confirmed per enquiry.
Confirm model MOQCompare modelsProduct documentationlite US A500C Product ManualEnglish PDF · Opens in a new tabView or download
✓ LiFePO4 cells✓ Pure sine wave output✓ Solar + AC charging
Technical specifications
US-A500C specifications
| Parameter | Specification |
|---|---|
| AC output | |
| Rated output | 500W |
| Waveform | Pure sine wave |
| AC voltage | 100–120V |
| AC frequency | 60Hz |
| USB-A | USB 3.0, 5V / 3A |
| USB-C | PD 20W |
| Battery | |
| Rated capacity | 800Wh |
| Chemistry | LiFePO4 |
| Cycle life | ≥6000 cycles |
| Charging & input | |
| PV input voltage | 12–60V |
| PV max input | 300W |
| AC input range | 85–135V (60Hz) |
| AC max charge | 500W |
| Charging modes | AC / PV |
| UPS bypass | EPS transfer <50ms |
| Physical | |
| Enclosure | Powder-coated metal |
| Form factor | Portable |
| Dimensions | 275 × 190 × 246mm |
| Net weight | 12.05kg |
| Gross weight | 13kg |
